Q&A

Q：为什么要用内网穿透
A：因为没有公网IP，现在的公网IP申请异常困难，甚至申请不到（工信部投诉中国移动也是一样的）

Q：内网穿透的工具有哪些
A：内网穿透的工具中比较有名的就是花生壳和FRP两种

Q：为什么不使用花生壳进行穿透
A：花生壳的免费版本只有1Mbps的带宽，而且只有两条映射。需要提高带宽或者映射就需要付费

Q：映射是什么
A：映射就是链接的线路，正常情况下SSH需要一条链路，部署一个项目需要一条，那么就没有映射了，而“物理服务器”肯定不只是部署一个项目，所以要么付费购买，要么另寻他路

Q：为什么使用FRP搭建内网穿透
A：FRP是免费的，而且没有映射线路的限制，虽然搭建的时候比花生壳麻烦，但是优点也很明显

Q：听说使用FRP需要使用域名+端口或者IP+端口
A：在不使用Nginx的时候确实需要，但是如果使用了Nginx的话，就可以直接使用域名进行访问了，如果没有域名，那确实是只能使用IP+端口的方式访问

Q：为什么需要云服务器
A：因为是自己搭建的FRP内网穿透，那么就需要一台拥有公网IP的服务器作为中转站

Q：云服务器的配置要什么要求
A：由于云服务器只是一个中转的服务器，因此CPU和内存方面没有太多的要求，可以使用现有的云服务器也可以开一台轻量服务器，因为轻量服务器性能和价格偏低，但是带宽会比ECS服务器高很多，所以轻量服务器会更划算

服务端

服务端也就是云服务器，FRP需要下载的版本是最新版本的Linux版本，不要最新版的话也可以自行下载，x86_64的处理器记得选择amd64.tar.gz版本
1、在Linux的/usr中新建文件夹frp，通过ftp将下载好的frp传入该文件夹内并且解压，然后删除frpc、frpc.ini、frpc_full.ini三个文件，会用到命令分别是：

(1)wget下载命令：


<span class="token function">wget</span> https://github.com/fatedier/frp/releases/download/v0.44.0/frp_0.44.0_linux_amd64.tar.gz
<span class="token function">wget</span> https://github.com/fatedier/frp/releases/download/v0.44.0/frp_0.44.0_linux_amd64.tar.gz
wget https://github.com/fatedier/frp/releases/download/v0.44.0/frp_0.44.0_linux_amd64.tar.gz

(2)解压命令：


<span class="token function">tar</span> -zxvf frp_0.44.0_linux_amd64.tar.gz
<span class="token function">tar</span> -zxvf frp_0.44.0_linux_amd64.tar.gz
tar -zxvf frp_0.44.0_linux_amd64.tar.gz

(3)进入frp文件夹


<span class="token builtin class-name">cd</span> frp_0.44.0_linux_amd64
<span class="token builtin class-name">cd</span> frp_0.44.0_linux_amd64
cd frp_0.44.0_linux_amd64

(4) 删除客户端配置文件


<span class="token function">rm</span> -rf frpc <span class="token function">rm</span> -rf frpc.ini <span class="token function">rm</span> -rf frpc_full.ini
<span class="token function">rm</span> -rf frpc <span class="token function">rm</span> -rf frpc.ini <span class="token function">rm</span> -rf frpc_full.ini
rm -rf frpc rm -rf frpc.ini rm -rf frpc_full.ini

2、修改、补充frps.ini配置文件


<span class="token function">vi</span> frps.ini
<span class="token function">vi</span> frps.ini
vi frps.ini

按下i键将下面信息根据自己需求进行修改


 bind_port <span class="token operator">=</span> <span class="token number">7000</span>  dashboard_port <span class="token operator">=</span> <span class="token number">7500</span>  subdomain_host <span class="token operator">=</span> xxxxx.com  token <span class="token operator">=</span> <span class="token number">123456</span>  dashboard_user <span class="token operator">=</span> xxxx  dashboard_pwd <span class="token operator">=</span> xxxx --------------------------------   vhost_http_port <span class="token operator">=</span> <span class="token number">8083</span>  vhost_https_port <span class="token operator">=</span> <span class="token number">8084</span> ---------------------------------  log_level <span class="token operator">=</span> info  log_max_days <span class="token operator">=</span> <span class="token number">999</span>  heartbeat_timeout <span class="token operator">=</span> <span class="token number">90</span>  max_pool_count <span class="token operator">=</span> <span class="token number">15</span>
 bind_port <span class="token operator">=</span> <span class="token number">7000</span>  dashboard_port <span class="token operator">=</span> <span class="token number">7500</span>  subdomain_host <span class="token operator">=</span> xxxxx.com  token <span class="token operator">=</span> <span class="token number">123456</span>  dashboard_user <span class="token operator">=</span> xxxx  dashboard_pwd <span class="token operator">=</span> xxxx --------------------------------   vhost_http_port <span class="token operator">=</span> <span class="token number">8083</span>  vhost_https_port <span class="token operator">=</span> <span class="token number">8084</span> ---------------------------------  log_level <span class="token operator">=</span> info  log_max_days <span class="token operator">=</span> <span class="token number">999</span>  heartbeat_timeout <span class="token operator">=</span> <span class="token number">90</span>  max_pool_count <span class="token operator">=</span> <span class="token number">15</span>
 bind_port = 7000  dashboard_port = 7500  subdomain_host = xxxxx.com  token = 123456  dashboard_user = xxxx  dashboard_pwd = xxxx --------------------------------   vhost_http_port = 8083  vhost_https_port = 8084 ---------------------------------  log_level = info  log_max_days = 999  heartbeat_timeout = 90  max_pool_count = 15

3、启动frps


./frps -c frps.ini
./frps -c frps.ini
./frps -c frps.ini

4、登录面板，使用ip+7500端口。输入账号密码，就可以看到面板了
5、这样的启动在不关闭ssh窗口的时候，是可以访问到的，但是一旦关闭了窗口就会关闭进程，所以要用Screen来运行
6、服务端的开机自启动可以不做也可以做，做的话参考客户端的开机自启动方法，我的建议是不做，因为云服务器重启后也是可以ssh连接上去的。

客户端

客户端就是家里的物理服务器，下载建议使用在线下载的方式，步骤跟服务端的1、2、3步一样的，第4步不一样，具体看
4、删除服务端的配置文件


<span class="token function">rm</span> -rf frps <span class="token function">rm</span> -rf frps.ini <span class="token function">rm</span> -rf frps_full.ini
<span class="token function">rm</span> -rf frps <span class="token function">rm</span> -rf frps.ini <span class="token function">rm</span> -rf frps_full.ini
rm -rf frps rm -rf frps.ini rm -rf frps_full.ini

5、添加、修改frpc.ini配置文件


<span class="token function">vi</span> frpc.ini
<span class="token function">vi</span> frpc.ini
vi frpc.ini

具体配置如下：


<span class="token punctuation">[</span>common<span class="token punctuation">]</span>  server_addr <span class="token operator">=</span> xx.xx.xx.xx  server_port <span class="token operator">=</span> <span class="token number">7000</span>  token <span class="token operator">=</span> <span class="token number">123456</span> <span class="token punctuation">[</span>ssh<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> tcp local_port <span class="token operator">=</span> <span class="token number">22</span> local_ip <span class="token operator">=</span> <span class="token number">127.0</span>.0.1 remote_port <span class="token operator">=</span> <span class="token number">8885</span> <span class="token punctuation">[</span>rdp<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> tcp local_ip <span class="token operator">=</span> <span class="token number">127.0</span>.0.1 local_port <span class="token operator">=</span> <span class="token number">3389</span> remote_port <span class="token operator">=</span> <span class="token number">7001</span> <span class="token punctuation">[</span>smb<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> tcp local_ip <span class="token operator">=</span> <span class="token number">127.0</span>.0.1 local_port <span class="token operator">=</span> <span class="token number">445</span> remote_port <span class="token operator">=</span> <span class="token number">7002</span> <span class="token punctuation">[</span>yi<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> http local_port <span class="token operator">=</span> <span class="token number">9050</span> subdomain <span class="token operator">=</span> yi <span class="token punctuation">[</span>bt<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> http local_port <span class="token operator">=</span> <span class="token number">8880</span> subdomain <span class="token operator">=</span> bt <span class="token punctuation">[</span>tuh<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> http local_port <span class="token operator">=</span> <span class="token number">10088</span> subdomain <span class="token operator">=</span> tuh <span class="token punctuation">[</span>tu<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> http local_port <span class="token operator">=</span> <span class="token number">10089</span> subdomain <span class="token operator">=</span> tu
<span class="token punctuation">[</span>common<span class="token punctuation">]</span>  server_addr <span class="token operator">=</span> xx.xx.xx.xx  server_port <span class="token operator">=</span> <span class="token number">7000</span>  token <span class="token operator">=</span> <span class="token number">123456</span> <span class="token punctuation">[</span>ssh<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> tcp local_port <span class="token operator">=</span> <span class="token number">22</span> local_ip <span class="token operator">=</span> <span class="token number">127.0</span>.0.1 remote_port <span class="token operator">=</span> <span class="token number">8885</span> <span class="token punctuation">[</span>rdp<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> tcp local_ip <span class="token operator">=</span> <span class="token number">127.0</span>.0.1 local_port <span class="token operator">=</span> <span class="token number">3389</span> remote_port <span class="token operator">=</span> <span class="token number">7001</span> <span class="token punctuation">[</span>smb<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> tcp local_ip <span class="token operator">=</span> <span class="token number">127.0</span>.0.1 local_port <span class="token operator">=</span> <span class="token number">445</span> remote_port <span class="token operator">=</span> <span class="token number">7002</span> <span class="token punctuation">[</span>yi<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> http local_port <span class="token operator">=</span> <span class="token number">9050</span> subdomain <span class="token operator">=</span> yi <span class="token punctuation">[</span>bt<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> http local_port <span class="token operator">=</span> <span class="token number">8880</span> subdomain <span class="token operator">=</span> bt <span class="token punctuation">[</span>tuh<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> http local_port <span class="token operator">=</span> <span class="token number">10088</span> subdomain <span class="token operator">=</span> tuh <span class="token punctuation">[</span>tu<span class="token punctuation">]</span> <span class="token builtin class-name">type</span> <span class="token operator">=</span> http local_port <span class="token operator">=</span> <span class="token number">10089</span> subdomain <span class="token operator">=</span> tu
[common]  server_addr = xx.xx.xx.xx  server_port = 7000  token = 123456 [ssh] type = tcp local_port = 22 local_ip = 127.0.0.1 remote_port = 8885 [rdp] type = tcp local_ip = 127.0.0.1 local_port = 3389 remote_port = 7001 [smb] type = tcp local_ip = 127.0.0.1 local_port = 445 remote_port = 7002 [yi] type = http local_port = 9050 subdomain = yi [bt] type = http local_port = 8880 subdomain = bt [tuh] type = http local_port = 10088 subdomain = tuh [tu] type = http local_port = 10089 subdomain = tu

[ssh]：这个就是项目服务的名称，不能重复
type：链接的协议，web服务就是http、https，ssh就是tcp，还有udp等
local_port：项目部署在客户端上使用的端口，不是外网访问的端口 local_ip：本地的ip，可以直接写127.0.0.1
subdomain：二级域名的前面部分，主域名我们在服务端已经设置好了
根据自己的需求添加或删除这些项目和端口

6、启动frp客户端


./frpc -c frpc.ini
./frpc -c frpc.ini
./frpc -c frpc.ini

到这里就完成了FRP的内网穿透的基本设置。
但是会遇到断电的问题或者重启的情况，那么这时候就需要设置FRP开机自启动
7、设置开机自启动
(1)使用pwd查看路径
(2)将frpc.ini文件复制到/etc/frpc文件夹里，如果没有这个文件夹，就使用mkdir新建一个


<span class="token function">sudo</span> <span class="token function">cp</span> frpc.ini /etc/frpc/frpc.ini
<span class="token function">sudo</span> <span class="token function">cp</span> frpc.ini /etc/frpc/frpc.ini
sudo cp frpc.ini /etc/frpc/frpc.ini

(3)将frpc复制到/usr/local/bin/bin/frpc下，没有的就新建一个


<span class="token function">sudo</span> <span class="token function">cp</span> frpc /usr/local/bin/frpc
<span class="token function">sudo</span> <span class="token function">cp</span> frpc /usr/local/bin/frpc
sudo cp frpc /usr/local/bin/frpc

(4)写入内容，输入的时候会自动新建文本


<span class="token function">sudo</span> <span class="token function">vi</span> /usr/lib/systemd/system/frpc.service
<span class="token function">sudo</span> <span class="token function">vi</span> /usr/lib/systemd/system/frpc.service
sudo vi /usr/lib/systemd/system/frpc.service

内容如下


<span class="token punctuation">[</span>unit<span class="token punctuation">]</span> <span class="token assign-left variable">Description</span><span class="token operator">=</span>frpc <span class="token assign-left variable">After</span><span class="token operator">=</span>multi-user.targe <span class="token punctuation">[</span>Service<span class="token punctuation">]</span> <span class="token assign-left variable">TimeoutStartSec</span><span class="token operator">=</span><span class="token number">30</span>  <span class="token assign-left variable">ExecStart</span><span class="token operator">=</span>/usr/local/bin/frpc -c /etc/frpc/frpc.ini <span class="token assign-left variable">ExecStop</span><span class="token operator">=</span>/bin/kill <span class="token variable">$MAINPID</span> <span class="token punctuation">[</span>Install<span class="token punctuation">]</span> <span class="token assign-left variable">WantedBy</span><span class="token operator">=</span>multi-user.target
<span class="token punctuation">[</span>unit<span class="token punctuation">]</span> <span class="token assign-left variable">Description</span><span class="token operator">=</span>frpc <span class="token assign-left variable">After</span><span class="token operator">=</span>multi-user.targe <span class="token punctuation">[</span>Service<span class="token punctuation">]</span> <span class="token assign-left variable">TimeoutStartSec</span><span class="token operator">=</span><span class="token number">30</span>  <span class="token assign-left variable">ExecStart</span><span class="token operator">=</span>/usr/local/bin/frpc -c /etc/frpc/frpc.ini <span class="token assign-left variable">ExecStop</span><span class="token operator">=</span>/bin/kill <span class="token variable">$MAINPID</span> <span class="token punctuation">[</span>Install<span class="token punctuation">]</span> <span class="token assign-left variable">WantedBy</span><span class="token operator">=</span>multi-user.target
[unit] Description=frpc After=multi-user.targe [Service] TimeoutStartSec=30  ExecStart=/usr/local/bin/frpc -c /etc/frpc/frpc.ini ExecStop=/bin/kill $MAINPID [Install] WantedBy=multi-user.target

(5)设置自动启动


<span class="token function">sudo</span> systemctl <span class="token builtin class-name">enable</span> frpc
<span class="token function">sudo</span> systemctl <span class="token builtin class-name">enable</span> frpc
sudo systemctl enable frpc

(6)启动frpc


<span class="token function">sudo</span> systemctl start frpc
<span class="token function">sudo</span> systemctl start frpc
sudo systemctl start frpc

(7)查看运行状态


<span class="token function">sudo</span> systemctl list-units <span class="token operator">|</span><span class="token function">grep</span> frpc
<span class="token function">sudo</span> systemctl list-units <span class="token operator">|</span><span class="token function">grep</span> frpc
sudo systemctl list-units |grep frpc


<span class="token function">sudo</span> systemctl status frpc
<span class="token function">sudo</span> systemctl status frpc
sudo systemctl status frpc
