一. 下载镜像

默认下载最新版本，如果想指定对应版本，可以用冒号后加版本，像这样mysql:5.7：


docker pull mysql:5.7 docker pull wordpress docker pull nginx
docker pull mysql:5.7 docker pull wordpress docker pull nginx
docker pull mysql:5.7 docker pull wordpress docker pull nginx

二. 启动container实例

已经下载好了image，接下来启动container，需要分别启动mysql，wordpress，nginx。

因为wordpress是需要安装数据库的，这里安装mysql并且启动：


docker container run -d <span class="token punctuation">\</span> --name wordpressdb <span class="token punctuation">\</span> -p <span class="token number">3306</span>:3306 <span class="token punctuation">\</span> --env <span class="token assign-left variable">MYSQL_ROOT_PASSWORD</span><span class="token operator">=</span><span class="token number">123456</span> <span class="token punctuation">\</span> --env <span class="token assign-left variable">MYSQL_DATABASE</span><span class="token operator">=</span>wordpress <span class="token punctuation">\</span> mysql:5.7
docker container run -d <span class="token punctuation">\</span> --name wordpressdb <span class="token punctuation">\</span> -p <span class="token number">3306</span>:3306 <span class="token punctuation">\</span> --env <span class="token assign-left variable">MYSQL_ROOT_PASSWORD</span><span class="token operator">=</span><span class="token number">123456</span> <span class="token punctuation">\</span> --env <span class="token assign-left variable">MYSQL_DATABASE</span><span class="token operator">=</span>wordpress <span class="token punctuation">\</span> mysql:5.7
docker container run -d \ --name wordpressdb \ -p 3306:3306 \ --env MYSQL_ROOT_PASSWORD=123456 \ --env MYSQL_DATABASE=wordpress \ mysql:5.7

各个参数含义：
-d: 指定容器以守护进程方式在后台运行；
--name: 指定容器名称，此处我指定的是wordpressdb；
-env 环境参数，MYSQL_ROOT_PASSWORD设置root用户的密码
-p: 指定主机与容器内部的端口号映射关系，
[宿主机端口号]：[容器内部端口]，此处我使用了主机3306端口，映射容器3306端口；
mysql:5.7 是nginx的镜像IMAGE ID前4位

这些参数中涉及了一些名词，如果看不懂，建议去看看docker的基本概念。简单来说就是，docker技术通过image这种模板，生成contaienr实例，下次还可以再生成一个contaienr实例，image像是一个模板，可以多次使用。contaienr实例可以看作小型的虚拟机，多个虚拟机在局域网里面，需要将端口映射到宿主机上面，我们都知道直接访问局域网的内网ip是不能访问的，通过宿主机的公网ip：映射的端口即可访问了。

docker安装wordpress，相比docker安装mysql，这里相比多了两个参数，后面会解释。如果安装成功，通过docker ps可以看到wordpress的进程，浏览器输入ip：8080，应该是可以在网页安装wordpress了。


docker run -d <span class="token punctuation">\</span> --name wordpress <span class="token punctuation">\</span> --link wordpressdb:mysql <span class="token punctuation">\</span> --volume <span class="token string">"<span class="token environment constant">$PWD</span>/wordpress"</span>:/var/www/html <span class="token punctuation">\</span> -p <span class="token number">8080</span>:80 <span class="token punctuation">\</span> wordpress
docker run -d <span class="token punctuation">\</span> --name wordpress <span class="token punctuation">\</span> --link wordpressdb:mysql <span class="token punctuation">\</span> --volume <span class="token string">"<span class="token environment constant">$PWD</span>/wordpress"</span>:/var/www/html <span class="token punctuation">\</span> -p <span class="token number">8080</span>:80 <span class="token punctuation">\</span> wordpress
docker run -d \ --name wordpress \ --link wordpressdb:mysql \ --volume "$PWD/wordpress":/var/www/html \ -p 8080:80 \ wordpress

--link：关联mysql容器，如果是使用非docker安装的mysql，比如自己手动安装的mysql，可以通过参数--env指定数据库连接：


-e <span class="token assign-left variable">WORDPRESS_DB_HOST</span><span class="token operator">=</span><span class="token number">192.168</span>.80.129:3306 <span class="token punctuation">\</span> -e <span class="token assign-left variable">WORDPRESS_DB_USESR</span><span class="token operator">=</span>root <span class="token punctuation">\</span> -e <span class="token assign-left variable">WORDPRESS_DB_PASSWORD</span><span class="token operator">=</span><span class="token number">123456</span>
-e <span class="token assign-left variable">WORDPRESS_DB_HOST</span><span class="token operator">=</span><span class="token number">192.168</span>.80.129:3306 <span class="token punctuation">\</span> -e <span class="token assign-left variable">WORDPRESS_DB_USESR</span><span class="token operator">=</span>root <span class="token punctuation">\</span> -e <span class="token assign-left variable">WORDPRESS_DB_PASSWORD</span><span class="token operator">=</span><span class="token number">123456</span>
-e WORDPRESS_DB_HOST=192.168.80.129:3306 \ -e WORDPRESS_DB_USESR=root \ -e WORDPRESS_DB_PASSWORD=123456

--volume：将容器的/var/www/html映射到当前目录下，这样直接操作当前目录，即可操作容器目录，否则还得进去容器操作，我们都知道容器是一个阉割版的小型虚拟机，像vim这种常用命令默认是没有的；

注意：wordpress容器默认开的是80端口，这里将容器的80端口映射到宿主机的8080端口，为什么不也映射到80端口呢，因为后面要安装nginx，nginx一般要监听80端口，云服务商一般配置域名：ikeguang.com绑定云主机的80端口，所以最后nginx只能由nginx占用宿主机的80端口，避免不必要的麻烦。

如果上面wordpress安装好了，网站可以通过ip地址正常访问，发布文章了，可以考虑绑定域名了，加个nginx进行反向代理。

nginx配置

http访问的时候，默认一个server监听80端口即可；如果配置https，需要加个server，监听443端口，这里先把http访问配置好再说，贴出了我的配置：


include /etc/nginx/conf.d/*.conf<span class="token punctuation">;</span> server<span class="token punctuation">{<!-- --></span> listen <span class="token number">80</span><span class="token punctuation">;</span> server_name ikeguang.com www.ikeguang.com<span class="token punctuation">;</span> location / <span class="token punctuation">{<!-- --></span> proxy_set_header Host <span class="token variable">$host</span><span class="token punctuation">;</span> proxy_set_header X-Forwarded-For <span class="token variable">$proxy_add_x_forwarded_for</span><span class="token punctuation">;</span> proxy_pass http://宿主机ip:8080<span class="token punctuation">;</span> <span class="token punctuation">}</span> <span class="token punctuation">}</span>
include /etc/nginx/conf.d/*.conf<span class="token punctuation">;</span> server<span class="token punctuation">{<!-- --></span> listen <span class="token number">80</span><span class="token punctuation">;</span> server_name ikeguang.com www.ikeguang.com<span class="token punctuation">;</span> location / <span class="token punctuation">{<!-- --></span> proxy_set_header Host <span class="token variable">$host</span><span class="token punctuation">;</span> proxy_set_header X-Forwarded-For <span class="token variable">$proxy_add_x_forwarded_for</span><span class="token punctuation">;</span> proxy_pass http://宿主机ip:8080<span class="token punctuation">;</span> <span class="token punctuation">}</span> <span class="token punctuation">}</span>
include /etc/nginx/conf.d/*.conf; server{ listen 80; server_name ikeguang.com www.ikeguang.com; location / { proxy_set_header Host $host; proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for; proxy_pass http://宿主机ip:8080; } }

这里http://宿主机ip:8080，因为前面我们的wordpress映射宿主机的端口是8080，这里nginx代理宿主机8080端口，也就是说你访问80端口(nginx)，相当于代理访问了8080端口(wordpress)，并且云服务商配置的域名也是绑定80端口，这样访问域名，就访问了8080端口的wordpress了，就能访问网站了。

说明：因我wordpress启动端口不是80，需要添加配置：


proxy_set_header Host <span class="token variable">$host</span><span class="token punctuation">;</span> proxy_set_header X-Forwarded-For <span class="token variable">$proxy_add_x_forwarded_for</span><span class="token punctuation">;</span>
proxy_set_header Host <span class="token variable">$host</span><span class="token punctuation">;</span> proxy_set_header X-Forwarded-For <span class="token variable">$proxy_add_x_forwarded_for</span><span class="token punctuation">;</span>
proxy_set_header Host $host; proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;

启动nginx容器
既然nginx.conf配置好了，接下来启动nginx容器：


docker run -d -p <span class="token number">80</span>:80 --name nginx -v /usr/share/nginx/html:/usr/share/nginx/html -v /etc/nginx:/etc/nginx -v /var/log/nginx:/var/log/nginx nginx
docker run -d -p <span class="token number">80</span>:80 --name nginx -v /usr/share/nginx/html:/usr/share/nginx/html -v /etc/nginx:/etc/nginx -v /var/log/nginx:/var/log/nginx nginx
docker run -d -p 80:80 --name nginx -v /usr/share/nginx/html:/usr/share/nginx/html -v /etc/nginx:/etc/nginx -v /var/log/nginx:/var/log/nginx nginx

这里需要注意：

这里将容器的目录/etc/nginx映射，需要先通过docker cp命令复制一份完整nginx的目录到宿主机，然后修改文件，再执行上面docker run命令。文件夹映射的时候，文件夹里面的所有文件应该是一样的，文件内容可以不一样。

经过前面的配置，通过域名应该可以访问网站了，接下来配置https：
nginx.conf配置：


include /etc/nginx/conf.d/*.conf<span class="token punctuation">;</span> server <span class="token punctuation">{<!-- --></span>  listen <span class="token number">443</span> ssl<span class="token punctuation">;</span>  server_name ikeguang.com www.ikeguang.com<span class="token punctuation">;</span> ssl_certificate ssl/1_ikeguang.com_bundle.crt<span class="token punctuation">;</span> ssl_certificate_key ssl/2_ikeguang.com.key<span class="token punctuation">;</span> ssl_session_timeout 5m<span class="token punctuation">;</span> ssl_protocols TLSv1 TLSv1.1 TLSv1.2<span class="token punctuation">;</span> ssl_ciphers ECDHE-RSA-AES128-GCM-SHA256:ECDHE:ECDH:AES:HIGH:<span class="token operator">!</span>NULL:<span class="token operator">!</span>aNULL:<span class="token operator">!</span>MD5:<span class="token operator">!</span>ADH:<span class="token operator">!</span>RC4<span class="token punctuation">;</span> ssl_prefer_server_ciphers on<span class="token punctuation">;</span> location / <span class="token punctuation">{<!-- --></span> proxy_set_header Host <span class="token variable">$host</span><span class="token punctuation">;</span> proxy_set_header X-Forwarded-For <span class="token variable">$proxy_add_x_forwarded_for</span><span class="token punctuation">;</span> proxy_pass http://宿主机ip:8080<span class="token punctuation">;</span> <span class="token punctuation">}</span> <span class="token punctuation">}</span> server<span class="token punctuation">{<!-- --></span> listen <span class="token number">80</span><span class="token punctuation">;</span> server_name ikeguang.com www.ikeguang.com<span class="token punctuation">;</span>  rewrite ^<span class="token punctuation">(</span>.*<span class="token punctuation">)</span>$ https://<span class="token variable">$host</span><span class="token variable">$1</span><span class="token punctuation">;</span>  location / <span class="token punctuation">{<!-- --></span> proxy_set_header Host <span class="token variable">$host</span><span class="token punctuation">;</span> proxy_set_header X-Forwarded-For <span class="token variable">$proxy_add_x_forwarded_for</span><span class="token punctuation">;</span> proxy_pass http://宿主机ip:8080<span class="token punctuation">;</span> <span class="token punctuation">}</span> <span class="token punctuation">}</span>
include /etc/nginx/conf.d/*.conf<span class="token punctuation">;</span> server <span class="token punctuation">{<!-- --></span>  listen <span class="token number">443</span> ssl<span class="token punctuation">;</span>  server_name ikeguang.com www.ikeguang.com<span class="token punctuation">;</span> ssl_certificate ssl/1_ikeguang.com_bundle.crt<span class="token punctuation">;</span> ssl_certificate_key ssl/2_ikeguang.com.key<span class="token punctuation">;</span> ssl_session_timeout 5m<span class="token punctuation">;</span> ssl_protocols TLSv1 TLSv1.1 TLSv1.2<span class="token punctuation">;</span> ssl_ciphers ECDHE-RSA-AES128-GCM-SHA256:ECDHE:ECDH:AES:HIGH:<span class="token operator">!</span>NULL:<span class="token operator">!</span>aNULL:<span class="token operator">!</span>MD5:<span class="token operator">!</span>ADH:<span class="token operator">!</span>RC4<span class="token punctuation">;</span> ssl_prefer_server_ciphers on<span class="token punctuation">;</span> location / <span class="token punctuation">{<!-- --></span> proxy_set_header Host <span class="token variable">$host</span><span class="token punctuation">;</span> proxy_set_header X-Forwarded-For <span class="token variable">$proxy_add_x_forwarded_for</span><span class="token punctuation">;</span> proxy_pass http://宿主机ip:8080<span class="token punctuation">;</span> <span class="token punctuation">}</span> <span class="token punctuation">}</span> server<span class="token punctuation">{<!-- --></span> listen <span class="token number">80</span><span class="token punctuation">;</span> server_name ikeguang.com www.ikeguang.com<span class="token punctuation">;</span>  rewrite ^<span class="token punctuation">(</span>.*<span class="token punctuation">)</span>$ https://<span class="token variable">$host</span><span class="token variable">$1</span><span class="token punctuation">;</span>  location / <span class="token punctuation">{<!-- --></span> proxy_set_header Host <span class="token variable">$host</span><span class="token punctuation">;</span> proxy_set_header X-Forwarded-For <span class="token variable">$proxy_add_x_forwarded_for</span><span class="token punctuation">;</span> proxy_pass http://宿主机ip:8080<span class="token punctuation">;</span> <span class="token punctuation">}</span> <span class="token punctuation">}</span>
include /etc/nginx/conf.d/*.conf; server {  listen 443 ssl;  server_name ikeguang.com www.ikeguang.com; ssl_certificate ssl/1_ikeguang.com_bundle.crt; ssl_certificate_key ssl/2_ikeguang.com.key; ssl_session_timeout 5m; ssl_protocols TLSv1 TLSv1.1 TLSv1.2; ssl_ciphers ECDHE-RSA-AES128-GCM-SHA256:ECDHE:ECDH:AES:HIGH:!NULL:!aNULL:!MD5:!ADH:!RC4; ssl_prefer_server_ciphers on; location / { proxy_set_header Host $host; proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for; proxy_pass http://宿主机ip:8080; } } server{ listen 80; server_name ikeguang.com www.ikeguang.com;  rewrite ^(.*)$ https://$host$1;  location / { proxy_set_header Host $host; proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for; proxy_pass http://宿主机ip:8080; } }

把前面启动http的nginx容器删除，配置好ssl证书，再次启动，需要启动80端口和443端口。


docker run -d -p <span class="token number">80</span>:80 -p <span class="token number">443</span>:443 --name nginx -v /usr/share/nginx/html:/usr/share/nginx/html -v /etc/nginx:/etc/nginx -v /var/log/nginx:/var/log/nginx nginx
docker run -d -p <span class="token number">80</span>:80 -p <span class="token number">443</span>:443 --name nginx -v /usr/share/nginx/html:/usr/share/nginx/html -v /etc/nginx:/etc/nginx -v /var/log/nginx:/var/log/nginx nginx
docker run -d -p 80:80 -p 443:443 --name nginx -v /usr/share/nginx/html:/usr/share/nginx/html -v /etc/nginx:/etc/nginx -v /var/log/nginx:/var/log/nginx nginx
